In short
- The regulations prescribe character shapes rather than allowing any bold sans serif typeface.
- Ordinary car-plate characters are 79 mm high, 50 mm wide and use a 14 mm stroke, with narrow exceptions for 1 and I.
- A legal plate also needs the correct spacing, materials, colours, markings and supplier details.
Calling it Charles Wright is useful shorthand. The enforceable part is the shape and measurement set in the display rules. A downloaded font with the right name does not make a road plate compliant by itself.
What font is used on UK number plates?
UK registration plates use the prescribed character style in Schedule 4 of the 2001 display regulations, commonly called Charles Wright. Since 1 September 2001, the standard face has replaced italic and decorative styles on new or replacement plates.
The regulations define a prescribed font as the style shown in Schedule 4 at the specified height. That is stronger than saying a plate needs a vaguely similar block typeface.
What makes the number plate characters distinctive?
The characters use heavy, simple outlines with controlled widths and little decoration. Narrow I and 1 are deliberate exceptions. Some pairs remain alike because the registration format supplies context that ordinary text would need from the letterform.
What are the official car-plate character dimensions?
INF104 gives ordinary post-2001 car characters as 79 mm high, 50 mm wide except for I and 1, and 14 mm thick. Characters sit 11 mm apart, with 33 mm between registration groups.
| Measure | Requirement |
|---|---|
| Character height | 79 mm |
| Character width | 50 mm, except 1 and I |
| Character stroke | 14 mm |
| Space between characters | 11 mm |
| Space between groups | 33 mm |
| Top, bottom and side margins | 11 mm minimum |
Motorcycle, tricycle, certain imported and older vehicle plates have separate provisions. The plate spacing checker keeps its answer bounded to supported formats for the same reason.
Why is the font only one part of a legal number plate?
A road plate also needs the correct character arrangement, spacing, reflective colours, supplier marking and applicable British Standard number. A correct typeface cannot rescue a rearranged registration or a non-compliant plate construction.
Current GOV.UK guidance says front plates use black characters on white and rear plates use black on yellow. Plates fitted after 1 September 2021 must carry BS AU 145e and use a single shade of black. Use a registered supplier for a road-going replacement.
Which official sources define the UK plate typeface?
Schedule 4 of the Road Vehicles (Display of Registration Marks) Regulations 2001 shows the prescribed shapes. DVLA leaflet INF104 gives the practical dimensions, while current GOV.UK guidance covers plate materials, colours and markings.
Read the prescribed font in the regulations, the DVLA INF104 leaflet and current GOV.UK plate rules. This site stores the characters as outlines so the preview and print file do not depend on a substituted device font.
Questions people actually ask
- What font is used on UK number plates?
- UK plates use the prescribed character style shown in Schedule 4 of the Road Vehicles (Display of Registration Marks) Regulations 2001. It is commonly called Charles Wright, but legal compliance depends on the prescribed shapes and dimensions rather than a font name alone.
- What size are letters on a UK number plate?
- For ordinary car plates fitted from 1 September 2001, INF104 gives a character height of 79 mm, a width of 50 mm except for 1 and I, and a 14 mm stroke. Separate provisions apply to motorcycles, some imports and older plates.
- Can I use a similar bold font on a UK number plate?
- Do not assume a similar bold font is compliant. The regulations prescribe a character style and identify departures that are not substantially similar. Buy road-use plates from a registered supplier who makes them to the current legal and British Standard requirements.
- Why do 0 and O look the same on a UK number plate?
- In the prescribed outline set used by this site, zero and capital O share the same shape. Their position inside a valid registration format supplies context. The typeface is designed for registration marks rather than for ordinary prose.
Written by Jonathan in Derby. Last updated .
